Service Box HP

Safe. Reliable. Simplified Maintenance.

Municipal digesters operate with biogas pressure higher than industrial or agricultural digesters. This allows for simpler biogas management without biogas booster blowers. The Service Box High Pressure (HP) has been specifically designed to meet the higher biogas pressure demanded at your municipal wastewater treatment plant. This Service Box is custom designed for municipal applications thanks to the corrosion resistant AISI 316 stainless steel construction, an integrated gas lock system to eliminate gas leakage during maintenance and Cl I, Div. 1 approved motors and cover plates.

Benefits at a glance

Efficient

Extended operating times with quick access for maintenance tasks

Flexible

Suitable for tanks with concrete or membrane roofs and for mixers with diameters of up to Ø1500mm (59inches)

Safe

Operating pressures of up to 18” of WC (45mbar) possible

Intelligent

Auto positioning system takes control over mixer positioning without operator interference

Robust

Robust stainless-steel construction

Servicebox HP Features

Schaubild Servicebox HP - Rührtechnik

Height adjustment and square guide tube mounting bracket

Inspection window complete with cleaning paper

Access step-ladder for winch assembly

Stainless steel construction in AISI 316 for durability

Power and Control wire cover plate (both sides)

Integrated base frame and lifting points

Removeable bottom access cover

Removeable front access cover

With the Service Box HP, the operation of mixers is greatly simplified. Adjusting the position and the height of the mixer can be done from outside the tank, thanks to the proven winch positioning system. This allows for optimized tank mixing and confidence that your complete tank volume is utilized. General mixer maintenance can be completed on the Service Box HP platform thanks to the removable access covers on the floor and the front. All of this is possible without biogas release or draining the tank. As a result, there is minimal or no impact on the biological process. That saves money and, of course, valuable time.

Service Box HP
Service Box HP
Service Box HP

Experience flexibility

  • Use of mixers from various manufacturers with a propeller diameter of up to 1500mm
  • Installation in tanks with level or concrete roofs possible
Service Box HP with gas lock
Service Box HP with gas lock
Service Box HP with gas lock

Uncompromising safety

  • Operating pressures of up to 18” of WC (45mbar) possible
  • Integrated biogas tie-in points to simplify installation
  • Spare instrument connections for pressure switches or biogas analyzers
Service Box HP with gas lock and installation frame
Service Box HP with gas lock and installation frame
Service Box HP with gas lock and installation frame

Quicker and easier maintenance

  • Two service openings for smaller and larger maintenance tasks provide quick access while maintaining safety
  • Prevent biogas loss using the patented gas lock
  • Integrated viewing glass for quick inspection of the tank interior
Service Box HP
Service Box HP
Service Box HP

PSM Mixer & Service Box HP

Retrofits made easy

The Service Box HP is ideal for installations in all anaerobic digesters and feedstock conditioning tanks including concrete and bolted steel roofs.

The standard square post has a cross-section of 150 x 150mm (6inch x 6inch) and can be delivered in lengths of up to 12m (40feet). This makes it possible to integrate the Service Box HP into a wide range of wastewater treatment facilities, industrial applications and biogas plants. Hundreds of plants in Europe and around the world already benefit from the advantages of the Service Box, including the convenient service opening for mixer maintenance and recovery without biogas discharge or hazardous tank entry.

The Service Box HP and our PSM mixer series make an ideal combination for your Omnivore concept!

Our extras

For even greater comfort

There are various attachments and accessories available for the Service Box HP. They can be optionally configured individually or as a package.
